Especially for engines with a power of up to 100 megawatts our oil mist separators ensure top separation performance and functional safety – thus, they can be used even for critical applications, such as a potentially explosive atmosphere. With a residual oil quantity of less than 5 mg/m³, the statutory limit values of the TA Luft are significantly undercut. When required, we provide all models in an ATEX certified design.
Safe and environmentally friendly
Our substantial separation performance of more than 99 % not only protects the environment but also your employees. Since the oil content of the combustion gases is significantly reduced, slippery surfaces, possible ignitions and oil in the atmosphere can be dealt with successfully.
Optimized crankcase pressure
You can best prevent an inadmissible pressure increase within the crankcase by using our UPF-OCV oil mist filters. With a regulated fan, the required underpressure inside the crankcase can also be regulated accurately for variable operating conditions. In addition, the low pressure loss of our UPF oil mist separators also saves costs by ensuring low power consumption.
Guaranteed reliability, even on the high seas
The specific requirements for engine operation on the high seas are given special consideration in our products. For use on ships or offshore platforms, we are the only manufacturer worldwide to offer oil mist separators approved by Germanischer Lloyd (GL) and RINA.
Worldwide unique: Approved by Germanischer Lloyd and RINA
Especially in the cruise ship industry, an increased environmental awareness, stricter obligations and requirements on cleanliness and safety lead to an increased need in oil mist separation. Being a pioneer in the industry, we have reacted to this early: As the worldwide only manufacturer, we provide oil mist separators which are approved by several international classification societies.
UPF-OCV specifications
- Coalescence filter
- Oil mist separation: 99.5 %
- Residual oil content after filtration: < 5 mg/m³
- Limit values of TA Luft are undercut
- Filtration: up to 0.1 μm droplet size
- ATEX certification: optional
- Germanischer Lloyd (GL) and RINA type approval: optional
- Maintenance-friendly, filter change intervals up to 24,000 hours; depending on the design, also up to 32,000 hours
Model overview UPF-OCV
| Model | Engine power | Blow-by flow rate |
|---|---|---|
| UPF-SAUKUL-X1A | ≤ 500 kW | ≤15 m³/h |
| UPF-SAUKUL-X3A | > 500 to 1.000 kW | ≤ 30 m³/h |
| UPF-SAUKUL-X3A-2M | > 1.000 to 2.000 kW | ≤ 60 m³/h |
| UPF-SAUKUL-X3A-3M | > 2.000 to 3.000 kW | ≤ 90 m³/h |
| UPF-SAUKUL-X3A-4M | > 3.000 to 4.000 kW | ≤ 120 m³/h |
| UPF-OCV-500-X1F | ≤ 3.200 kW | ≤ 100 m³/h |
| UPF-OCV-500-X2F | > 3.200 to 6.400 kW | ≤ 200 m³/h |
| UPF-OCV-844-X1M | > 6.400 to 11.500 kW | ≤ 350 m³/h |
| UPF-OCV-844-X2M | > 11.500 to 23.000 kW | ≤ 700 m³/h |
| UPF-OCV-844-X3M | > 23.000 to 35.000 kW | ≤ 1.050 m³/h |
| UPF-OCV-844-X4M | > 35.000 to 46.000 kW | ≤ 1.400 m³/h |
Open vs. closed crankcase ventilation
Open crankcase ventilation
Closed crankcase ventilation
